¶ Ansible İle RKE2 Kubernetes Cluster Kurulumu
Hazırlamış olduğum dokümantasyon ile ansible kullanlarak 3 master 3 worker node'dan oluşan bir kubernetes cluster kurulumu yapacağız. Kurulumu RHEL8.6 üzerinde gerçekleştireceğim. Kurulumda öncelikle tüm node'larda selinux ve swap kapatıyoruz. Daha sonra network için konfigürasyonlar yapılacaktır. İlk master sunucu kurulumu yapılır diğer master ve worker'ların join olabilmesi için gerekli token'i elde edeceğim. Daha sonra sahip olduğumuz token ile diğer node'ların kurulumu yapılacaktır. Node sayılarını arttırmak isterseniz inventory dosyasına eklemeniz yeterlidir.
RKE2 Kurulumu default olarak /var/lib/rancher dizinine kurulmaktadır. İlgili dizini LVM ile ayırmanızı tavsiye ederim. LVM için notlar bölümünde paylaştım.
ilgili Yml dosyaları için;
https://github.com/emrahuludag/rke-cluster-installation
¶ Dizin Ağaç Yapısı
.
├── inventory.ini
├── main.yml
├── roles
│ ├── installation
│ │ └── tasks
│ │ ├── install_master.yml
│ │ ├── join_master.yml
│ │ ├── join_worker.yml
│ └── requirements
│ └── tasks
│ └── requirements.yml
└── vars
└── vars.yml
¶ Playbook Dosyaları
inventory.ini
[allnode:children]
master-firstnode
master-nextnodes
workers
[master-firstnode]
rke2-node1 ansible_host=192.168.1.1
[master-nextnodes]
rke2-node2 ansible_host=192.168.1.2
rke2-node2 ansible_host=192.168.1.3
[workers]
rke2-worker-node1 ansible_host=192.168.1.4
rke2-worker-node2 ansible_host=192.168.1.5
rke2-worker-node3 ansible_host=192.168.1.6
[allnode:vars]
ansible_user = root
remote_tmp = /tmp/.ansible-${USER}/tmp
ansible_python_interpreter=/usr/bin/python3
ansible_ssh_common_args = "-o StrictHostKeyChecking=no -o UserKnownHostsFile=/dev/null"
vars.yml
##Installing ENV
confvar: "/var/lib/rancher/rke2/server"
confdir: "/etc/rancher/rke2"
conffile: "{{ confdir }}/config.yaml"
clustername: "test"
kubeconfig: "/etc/rancher/rke2/rke2.yaml"
requirements.yml
---
- name: Disable SELinux
selinux:
state: disabled
- name: Swapoff
shell: swapoff -a
- name: Disable Swap permanently
replace:
path: /etc/fstab
regexp: '^(\s*)([^#\n]+\s+)(\w+\s+)swap(\s+.*)$'
replace: '#\1\2\3swap\4'
backup: yes
- name: Network Requirements
shell: |
sudo cat << EOF | sudo tee /etc/modules-load.d/containerd.conf
overlay
br_netfilter
EOF
sudo cat << EOF | sudo tee /etc/sysctl.d/99-kubernetes-cri.conf
net.ipv4.ip_forward = 1
net.bridge.bridge-nf-call-iptables = 1
net.bridge.bridge-nf-call-ip6tables = 1
EOF
sudo modprobe overlay
sudo modprobe br_netfilter
sudo sysctl --system
- name: Install Kubernetes Python dependencies
pip:
name: kubernetes
install_master.yml
---
- name: Create RKE2 Directory
file:
path: "{{ confdir }}"
state: directory
owner: root
group: root
mode: '0770'
recurse: yes
- name: Installing RKE2 Server
shell: |
curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE=server sh -
- name: Start rke2-server service
service:
name: rke2-server
state: started
enabled: yes
- name: Simlink kubectl
shell: |
ln -s $(find /var/lib/rancher/rke2/data/ -name kubectl) /usr/local/bin/kubectl
ignore_errors: yes
- name: Append /var/lib/rancher/rke2/bin/ to PATH env
lineinfile:
path: /root/.bash_profile
line: export KUBECONFIG=/etc/rancher/rke2/rke2.yaml
create: yes
backup: yes
- name: Create RKE2 config.yaml for joining
shell: "echo server: https://{{ ansible_host }}:9345 > {{ confvar }}/config.yaml; \
echo token: $(cat {{ confvar }}/node-token) >> {{ confvar }}/config.yaml"
- name: Fetch Token From Master
fetch:
src: "{{ confvar }}/config.yaml"
dest: "/tmp/rke2_{{ clustername }}_config.yaml"
flat: yesjoin_master.yml
---
- name: Create RKE2 Directory
file:
path: "{{ confdir }}"
state: directory
owner: root
group: root
mode: '0770'
recurse: yes
- name: Installing RKE2 Server
shell: |
curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE=server sh -
- name: Copy Master Rancher Config file
copy:
src: /tmp/rke2_{{ clustername }}_config.yaml
dest: /etc/rancher/rke2/config.yaml
owner: root
group: root
mode: '0660'
- name: Start rke2-server service
service:
name: rke2-server
state: started
enabled: yes
- name: Simlink kubectl
shell: |
ln -s $(find /var/lib/rancher/rke2/data/ -name kubectl) /usr/local/bin/kubectl
ignore_errors: yes
- name: Append /var/lib/rancher/rke2/bin/ to PATH env
lineinfile:
path: /root/.bash_profile
line: export KUBECONFIG=/etc/rancher/rke2/rke2.yaml
create: yes
backup: yes
join_worker.yml
---
- name: Create RKE2 Directory
file:
path: "{{ confdir }}"
state: directory
owner: root
group: root
mode: '0770'
recurse: yes
- name: Installing RKE2 Agent on Workers
shell: |
curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE=agent sh -
- name: Copy Master Rancher Config file
copy:
src: /tmp/rke2_{{ clustername }}_config.yaml
dest: /etc/rancher/rke2/config.yaml
owner: root
group: root
mode: '0660'
- name: Start rke2-agent service
service:
name: rke2-agent
state: started
enabled: yes
- name: Simlink kubectl
shell: |
ln -s $(find /var/lib/rancher/rke2/data/ -name kubectl) /usr/local/bin/kubectl
ignore_errors: yes
- name: Append /var/lib/rancher/rke2/bin/ to PATH env
lineinfile:
path: /root/.bash_profile
line: export KUBECONFIG=/etc/rancher/rke2/rke2.yaml
create: yes
backup: yes
main.yml
---
- hosts: allnode
become: yes
tasks:
- name: Install requirements (swap,etc,folders)
include_role:
name: requirements
tasks_from: requirements.yml
- hosts: master-firstnode
become: yes
tasks:
- name: Include vars
include_vars:
dir: vars
- name: Install RKE2 Master Server
include_role:
name: installation
tasks_from: install_master.yml
- hosts: master-nextnodes
become: yes
tasks:
- name: Include vars
include_vars:
dir: vars
- name: Install RKE2 Next Master Nodes
include_role:
name: installation
tasks_from: join_master.yml
- hosts: workers
become: yes
tasks:
- name: Include vars
include_vars:
dir: vars
- name: Install RKE2 Next Master Nodes
include_role:
name: installation
tasks_from: join_worker.yml
¶ Playbook Çalıştırılması
Sunuculara ssh_key ile root erişilir.
ansible-playbook main.yml -i inventory.ini
Output
PLAY [allnode] ***********************************************************************************************************************************************************
TASK [Gathering Facts] ***************************************************************************************************************************************************
ok: [rke2-worker-node1]
ok: [rke2-worker-node3]
ok: [rke2-worker-node2]
ok: [rke2-node3]
ok: [rke2-node2]
ok: [rke2-node1]
TASK [Install requirements (swap,etc,folders)] ***************************************************************************************************************************
ok: [rke2-worker-node3]
ok: [rke2-node2]
ok: [rke2-worker-node1]
ok: [rke2-worker-node2]
ok: [rke2-node1]
ok: [rke2-node3]
TASK [requirements : Disable SELinux] ************************************************************************************************************************************
ok: [rke2-worker-node3]
ok: [rke2-node2]
ok: [rke2-worker-node1]
ok: [rke2-worker-node2]
ok: [rke2-node1]
ok: [rke2-node3]
TASK [requirements : Swapoff] ********************************************************************************************************************************************
changed: [rke2-worker-node1]
changed: [rke2-node1]
changed: [rke2-node2]
changed: [rke2-node3]
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
TASK [requirements : Disable Swap permanently] ***************************************************************************************************************************
ok: [rke2-worker-node2]
ok: [rke2-worker-node1]
ok: [rke2-worker-node3]
ok: [rke2-node1]
ok: [rke2-node2]
ok: [rke2-node3]
TASK [requirements : Network Requirements] *******************************************************************************************************************************
changed: [rke2-node1]
changed: [rke2-node2]
changed: [rke2-node3]
changed: [rke2-worker-node1]
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
TASK [requirements : Install Kubernetes Python dependencies] *************************************************************************************************************
ok: [rke2-node1]
ok: [rke2-worker-node3]
ok: [rke2-worker-node1]
ok: [rke2-worker-node2]
ok: [rke2-node2]
PLAY [master-firstnode] **************************************************************************************************************************************************
TASK [Gathering Facts] ***************************************************************************************************************************************************
ok: [rke2-node1]
TASK [Include vars] ******************************************************************************************************************************************************
ok: [rke2-node1]
TASK [Install RKE2 Master Server] ****************************************************************************************************************************************
TASK [installation : Create RKE2 Directory] ******************************************************************************************************************************
changed: [rke2-node1]
TASK [installation : Installing RKE2 Server] *****************************************************************************************************************************
changed: [rke2-node1]
TASK [installation : Start rke2-server service] **************************************************************************************************************************
changed: [rke2-node1]
TASK [installation : Simlink kubectl] ************************************************************************************************************************************
changed: [rke2-node1]
TASK [installation : Append /var/lib/rancher/rke2/bin/ to PATH env] ******************************************************************************************************
ok: [rke2-node1]
TASK [installation : Create RKE2 config.yaml for joining] ****************************************************************************************************************
changed: [rke2-node1]
TASK [installation : Fetch Token From Master] ****************************************************************************************************************************
changed: [rke2-node1]
PLAY [master-nextnodes] **************************************************************************************************************************************************
TASK [Gathering Facts] ***************************************************************************************************************************************************
ok: [rke2-node2]
TASK [Include vars] ******************************************************************************************************************************************************
ok: [rke2-node2]
TASK [Install RKE2 Next Master Nodes] ************************************************************************************************************************************
TASK [installation : Create RKE2 Directory] ******************************************************************************************************************************
changed: [rke2-node2]
TASK [installation : Installing RKE2 Server] *****************************************************************************************************************************
changed: [rke2-node2]
TASK [installation : Copy Master Rancher Config file] ********************************************************************************************************************
changed: [rke2-node2]
TASK [installation : Start rke2-server service] **************************************************************************************************************************
changed: [rke2-node2]
TASK [installation : Simlink kubectl] ************************************************************************************************************************************
changed: [rke2-node2]
TASK [installation : Append /var/lib/rancher/rke2/bin/ to PATH env] ******************************************************************************************************
ok: [rke2-node2]
PLAY [workers] ***********************************************************************************************************************************************************
TASK [Gathering Facts] ***************************************************************************************************************************************************
ok: [rke2-worker-node1]
ok: [rke2-worker-node2]
ok: [rke2-worker-node3]
TASK [Include vars] ******************************************************************************************************************************************************
ok: [rke2-worker-node1]
ok: [rke2-worker-node2]
ok: [rke2-worker-node3]
TASK [Install RKE2 Next Master Nodes] ************************************************************************************************************************************
TASK [installation : Create RKE2 Directory] ******************************************************************************************************************************
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
changed: [rke2-worker-node1]
TASK [installation : Installing RKE2 Agent on Workers] *******************************************************************************************************************
changed: [rke2-worker-node1]
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
TASK [installation : Copy Master Rancher Config file] ********************************************************************************************************************
changed: [rke2-worker-node1]
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
TASK [installation : Start rke2-agent service] ***************************************************************************************************************************
changed: [rke2-worker-node3]
changed: [rke2-worker-node2]
changed: [rke2-worker-node1]
TASK [installation : Simlink kubectl] ************************************************************************************************************************************
changed: [rke2-worker-node1]
changed: [rke2-worker-node2]
changed: [rke2-worker-node3]
TASK [installation : Append /var/lib/rancher/rke2/bin/ to PATH env] ******************************************************************************************************
ok: [rke2-worker-node1]
ok: [rke2-worker-node3]
ok: [rke2-worker-node2]
PLAY RECAP ***************************************************************************************************************************************************************
rke2-node1 : ok=15 changed=8 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
rke2-node2 : ok=14 changed=7 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
rke2-node3 : ok=14 changed=7 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
rke2-worker-node1 : ok=14 changed=7 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
rke2-worker-node2 : ok=14 changed=7 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
rke2-worker-node3 : ok=14 changed=7 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
[root@akfrancherm01 ~]# kubectl get nodes
NAME STATUS ROLES AGE VERSION
akfrancherm01 Ready control-plane,etcd,master 10m v1.24.7+rke2r1
akfrancherm02 Ready control-plane,etcd,master 7m45s v1.24.7+rke2r1
akfrancherm03 Ready control-plane,etcd,master 7m41s v1.24.7+rke2r1
akkrancherw01 Ready <none> 5m49s v1.24.7+rke2r1
akfrancherw02 Ready <none> 5m50s v1.24.7+rke2r1
akfrancherw03 Ready <none> 5m52s v1.24.7+rke2r1
¶ NOTLAR
Node'u silmeniz gerekmesi durumunda aşağıdaki hazır script ile temizleyebilirsiniz. BKZ: https://docs.rke2.io/install/linux_uninstall/
/usr/bin/rke2-uninstall.sh
#
rm -rf /usr/local/bin/kubectl
LVM ile /var/lib/rancher dizinin ayrılması
pvcreate /dev/sdb
#
vgcreate -s 16m rancher_vg /dev/sdb
#
lvcreate -L 100%FREE -n rancher_lv rancher_vg
#
mkfs.xfs /dev/mapper/rancher_vg-rancher_lv
#
mkdir -p /var/lib/rancher
#
echo "####################################################################" >> /etc/fstab
#
echo "/dev/mapper/rancher_vg-rancher_lv /var/lib/rancher xfs defaults 0 0" >> /etc/fstab
#
mount /var/lib/rancher
#
